led panel light 18W square shape 5 years life time with CE RHOS

LED panel light 18W square
Dimmable is available
Energy saved up to 80%
CE RHOS approved


led panel light 18W square shape 225x225x12.8mm 5 years life time


1 Environment friendly, energy saving (80-90%).
2 Low heat, low power consumption / High-brightness.
3 No RF interference, No IR/UV radiation, no mercury pollution.
4 Easy installtion maintenance free.
5 Long lifespan: 50,000hours.
6 The voltage and lamp tap can meet the requirements of the customer.
7 High-brightness, thermal little, good color.
8 Dimmable, Sensor, Emergency can be choose.
9 CE Certificate & ROHS.



ultra thin led square panel light (Dimmable is available)

Item Code Wattage Lumens Size mm Cut
MS-SPL-3W 3W 280-300LM 85*85*12.8 75*75
MS-SPL-6W 6W 550-600LM 120*120*12.8 105*105
MS-SPL-9W 9W 800-900LM 146*146*12.8 135*135
MS-SPL-12W 12W 1100-1200LM 175*175*12.8 155*155
MS-SPL-15W 15W 1400-1500LM 200*200*12.8 185*185
MS-SPL-18W 18W 1650-1800LM 225*225*12.8 205*205
MS-SPL-21W 21W 1950-2100LM 237*237*12.8 220*220
MS-SPL-24W 24W 2200-2400LM 300*300*12.8 280*280
Voltage: AC85-265V/DC12V/DC24V

Luminous efficiency: 90-120LM/W

CCT/Colors: Warm white, Pure white, Cool white or RGB

LED source: 2835 SMD Epistar

Beam angle: 120°

PF: >0.9

Ra: >80

Installation: embedded installation

Certificates: CE RHOS

Warranty Period(years) : 3 years


Widely used in homes, offices, restaurants, hotels, buses, trains, warehourses, parking losts est meeting room school, library,factory, warehouse, casino, parking garage, hospital, commercial center, supermarket, shopping mall and etc.


Packaging & Shipping

Standard export packing, color box or neutral white box
