dimmable led panel light 1200 300 build in recessed or suspended installation

led panel light 1200 x 300mm
Dimmable is available
50, 000 hours average LED life span
Suspension or Embedded


dimmable led panel light 1200 300 build in recessed or suspended installation


1.Dimmable is available
2.Build in recessed or suspended installation
3.LED panel light with external power supply,driver input voltage AC85-250V,50/60HZ,lighting input voltage dc24v,constant voltage.
4.PF>0.95,power efficiency>0.85.
5.Material:AL+PMMA+PC Diffuser.
6.Protection grade ip42,insulation class II.
7.Ambient temperature:-20°c~ 45°c ,surface temperature: 42°c~ 45°c,Relative humidity 10%~80%RH.
8.Energy-saving,super bright.Environmental-friendly,saving 65% energy than the traditional panel lights.
9.Uniform light output,bright and confortable alleviating eye fatigue,wide beam angle.
10.Under the condition of voltage instability,the led panel light could work properly by using the constant-current led driver.


Technical Details

led panel light 1200x300mm (Dimmable is available)

Item No. MS-1200*300-36W
Power 36W
Lumen(LM) 3200-3600Lm
RA >80
PF >0.9
Dimmable available
Size 1200*300*10MM
Installation Suspension or Embedded
Weight 3.8kg
Export Carton size 125*35*3cm
Power Factor >0.9
Material Alum.
CCT Warm White:2700-3500k
CCT Natural White:4000-4500k
CCT Cool White:6000-6500K
MOQ 1 Piece
lifespan 50,000 hours
Voltage Frequency AC85~277V
Warranty 3 years


Apply to office; Passageway; Hotel; Room; Exhibition, hospital, Hall etc.

led panel light applictions

Packaging & Shipping

Standard export packing, color box or neutral white box
