IP67 20KV Zigbbe control LED stadium lights 1000W asymmetric flood light
LED stadium lights
IP67
Zigbbe control
20KV anti-surge
- Description
- Contact From
Description
IP67 20KV Zigbbe control LED stadium lights 1000W asymmetric flood light
Features
Our new LED stadium lights 1000W is Low-profile, lightweight, powerful and reliable. Designed with high protection level up to IP67, High impact resistance, high vibration resistance and Anti 17-level wind power.
Wide wattage options of 300W 400W 500W 600W 750W 950W 1200W replacing metal halide/high pressure sodium of 1000~2500W with a 100,000 hours lifespan.
High lumen efficiency of up to 128LM/W, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.
The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs. Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.
Various distribution option for various applications, 20°*20° 30°*30° 40°*40° 60°*60° 90°*90° option.
Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smartphone.
specifications
Power | 300W | 400W | 500W | 600W | 750W | 950W | 1200W |
Luminous Flux | 38,486 lm | 50,520 lm | 56,614 lm | 76,819 lm | 84,374 lm | 115,344 lm | 134,087 lm |
Gross Weight | 13.7kgs / 30.2 lbs | 14kgs / 30.9 lbs | 14.1 kgs / 31.1 lbs | 19.4 kgs / 42.8 lbs | 19.5 kgs / 43 lbs | 27 kgs / 59.5 lbs | 28 kgs / 61.7 lbs |
Input Voltage | 100-277V/347-480V | ||||||
Power Factor | >0.95 | ||||||
CRI | ≥70Ra, or ≥90Ra | ||||||
Driver | Meanwell | ||||||
Light Distribution | 20°*20° 30°*30° 40°*40° 60°*60° 90°*90° | ||||||
Color Temp. | 3000K/4000K/5000K/5700K/6500K (others available) | ||||||
Dimming Options | 0-10V dimming / Zigbee wireless dimming available | ||||||
Zigbee Control | On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP). | ||||||
Photocontrol | Twist-lock photocell available | ||||||
SPD | 20kV SPD standard (40kV optional) | ||||||
IP Rating | IP67 | ||||||
Operating Temp. | -40°C- 40°C / -40°F – 104°F | ||||||
Lifespan | >100,000 Hrs (L70 @ 25°C) | ||||||
Warranty | 7-year warranty for 100-277V version, 5-year warranty for 347-480V version | ||||||
Certificates | UL/CB/CE/ENEC/ROHS/PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC (pending) |
Details
High thermal conductivity
We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)
Slim and Lightweight
Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.
Extraordinary Thermal Management
The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.
UV stabilized optic lens
20°*20° 30°*30° 40°*40° 60°*60° 90°*90°
Intelligent Zigbee controller
Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smartphone.
Applications
LED stadium lights 1000W is Idea for outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
Packaging & Shipping
Standard export packaging
