Seamless Connection Aluminium Led Linear Pendant Lighting Available In Suspended And Surface Mount
Seamless Connection
Aluminium
Led Linear Pendant Lighting
Available In Suspended And Surface Mount
- Description
- Contact From
Description
Seamless Connection Aluminium Led Linear Pendant Lighting Available In Suspended And Surface Mount
Features
linear led light fixture
1.Freedom Design
The design of LED Linear Light breaks through the limitations of traditional lighting design,the length of extrusion profiles can be cuttable according your request,even infinite connection for each other. Let everyone enjoy the freedom of design.
2.Easier Installation
Based on the modular design,the installation of LED linear light is diversified such as wall mounted,ceiling mounted, recessed or wire suspended according your application,the installation can be completed more quickly by this design.
3.More Various Application
Unlike the application of LED strip or LED tube light,a variety of application environments with good adaptability through the perfect combination of aluminum and LED light source.While providing a variety of joint accessories,the spatial structure has demonstrated a perfect compatibility in different areas.
4.More fashion modeling
Different from the complex,luxurious European lighting style,using LED linear lighting system to cut the space for a variety of simple geometric shapes,opened a fresh,elegant stylish lighting new field,will become the new trend in recent years.
Technical parameters
suspended linear led lighting
| led linear pendant 3570 | |
| Product name | LED Linear Light – 3570 |
| Product Model No | LS3567-PZ |
| Housing material | 6063-T5 |
| Surface treatment | Powder coated or Brushed aluminum |
| CCT | 3000K,4000K,6000K |
| LEDs | 2835SMD (SANAN chip) |
| LEDs Life Span | 50000H |
| Input Voltage | 100-277V/200-240V 50/60HZ |
| Power supplier | Flicker-free |
| Luminous Efficacy(lm/w) | 100lm/W |
| Color Render (CRI) | RA≥80 or RA≥90 |
| Power factory(PF) | ≥0.9 |
| Optional features : | 0-10V dimming, DALI dimming,CCT dimming |
| IP Rated | IP20 |
| Beam Angle | 120° (PC) |
| 34°(Reflector) | |
| Working Temp(℃) | Surrounding Ambiance Temperature -25°~40°Degree Celsius |
| Body Material | aluminum,PC,ABS |
| Color Option(shell) | Silver,White,Black |
| Certification | CE, RoHS |
| Limited Warranty | 3 Years |
| Standard specifications | ||||
| Model | Size | Watts | Voltage | CRI |
| 3570LS20W06-PZ | L605*W35*H70 | 20W | AC200-240V/100-277v | Ra>80/90 |
| 3570LS40W12-PZ | L1200*W35*H70 | 40W | AC200-240V/100-277v | Ra>80/90 |
| 3570LS60W18-PZ | L1795*W35*H70 | 60W | AC200-240V/100-277v | Ra>80/90 |
| 3570LS80W24-PZ | L2390*W35*H70 | 80W | AC200-240V/100-277v | Ra>80/90 |
Details
suspended linear led lighting
linear led light fixture
1.Connect with seamless, form with line shape.
2.Product can be used hanging ,surface mounted, recessed installation.
3.Cap with PC plastic moulding , connect with PC cover with seamless which let the light can’t run out.
4.Aluminum PCB with no-facula design, connection by rotate installing which conveniently and easily.
5.PC cover transmitting rate reach 86%, luminous reach 110lm/w.
6.IC driver. No flicker, No glaring.CIR ≥ 80.PF ≥ 0.9 and corrosion.
6.Product passed TUV SAA CE FCC ROSH certifications.
LED linear light for Office Supermarket, Can be customized in a wide range of sizes
A. Shopping mall, supermarket, hotel lighting, office lighting etc.;
B. Family house, kithchen, warehouse, bathroom, corridor, garage;
C. Commercial show windows and bars, subway, airport, exhibition hall, gymnasium etc.
Applications
LED linear lighting Use in shopping mall, office, school, leisure site, garage, factory, school, supermarket, hospital, store, etc.
Packaging & Delivery
Neutral packing, Or customize packaging according to customer requirements.
