Underwater IP68 3000W Green LED Fishing Light Squid Fishing Lights Attracting Light
Underwater IP68 Waterproof level
600W – 3000W
Green LED Fishing Light Squid Fishing Lights Attracting Light
- Description
- Contact From
Description
Underwater IP68 3000W Green LED Fishing Light Squid Fishing Lights Attracting Light
Features
1. Beautiful appearance design
2. Long lifespan >50,000 hours
3. Wide voltage, with AC190-240V / AC90-130V
4. Green Light, environmental protection
5. Low power consumption, high efficiency, economic
6. Available color: White, Green, Red, Yellow or Blue
7. CE and RoHS approval, IP68
8. Offer OEM service
Technical parameter
White/green underwater fishing light
| Model | Power | Lamp Current | Input Voltage | Initial Lumen | CRI | PF | Luminous Efficiency | IP Grade | G.W |
| LED Fishing Lights | |||||||||
| LED 100W | 100 | 4.1A | DC12-24V | 110000lm | 85Ra | >0.96 | 130lm | IP68 | 2.5KG |
| LED 500W | 500 | 6.2A | AC220V 50Hz | 65000lm | 85Ra | >0.96 | 130lm | IP68 | 8.8KG |
| LED 600W | 600 | 9.2A | AC220V 50Hz | 65000lm | 85Ra | >0.96 | 130lm | IP68 | 12.5KG |
| LED 1000W | 1000 | 9.2A | AC220V 50Hz | 130000lm | 85Ra | >0.96 | 130lm | IP68 | 12.5KG |
| LED 2000W | 2000 | 13.8A | AC220V 50Hz | 130000lm | 85Ra | >0.96 | 130lm | IP68 | 18KG |
Details
Attract fishing led light
1. The lamp applied in deep water fishing, LED light source, energy saving and environment friendly, there is excellent effect on luring and inducing the fish.
2. Light trapping is the use of photo taxis of fish and insects, according to this theory, luring the fish and other insects.
3. Setting strong light to lure the fish into the pre-set a good net, and then using the pulley by force, lifting the net and the fish by catch quickly to surface of water.
4. Strong corrosion resistance, double waterproof, the most waterproof depth arrives 100 meters.
Wire connection
| Wire | Three-core 0.75 mm2 |
| Wire connection | Brown – L |
| Blue – N | |
| Yellow/Green – Ground |
Applications
Fishery: to promote the hatchery and growth of the fish;
Fishing: installed on the boat to attract the fishes when fishing in the sea.
Factory
Packaging & Shipping
Standard export packing, color box or neutral white box
