5 year warranty IP65 factory warehouse industrial 150w led high bay light

5 year warranty IP65 factory warehouse industrial 150w led high bay light

5 year warranty
IP65 factory warehouse industrial
150w led high bay light
CE ROHS FCC approved

  • Description
  • Contact From

5 year warranty IP65 factory warehouse industrial 150w led high bay light


1, The light source adopts the integration of imported single high power LED, with the special design of integrating many chips into one lighting source.
2, Integrative design for heat sink and housing ensure 50,000 hours life-span for the LED. If it works 11-12 hours per day, it can work over 10 years.
3, The high purity aluminum from Germany as the reflector is at high reflecting efficiency, which improves the efficiency of light uniformity and utilization, and shows the LED advantage of energy saving.
4, Wide range of input voltage: AC85-265V. New high efficiency constant current driver.
5, Can present the original color of the objects, it has varies of colors to choose which can meet the requirements in different environments. It eliminates the dullness of environments caused by the lower color temperature, like sodium lamp, or higher color temperature, like mercury lamp.
6, No delay start. It can reach normal lighting as soon as it is turned on. No noise.
7, Use powerful LED light source and high efficiency imported LED driver. Compare with sodium lights, it can save electricity around 60%.
8, Environment friendly and no air pollution. We exert the design of using cold light source. It no heat radiation. There is no ill to our eyes and skin. The floodlights do not have lead, hydrargyrum and any other contamination. It is really environment friendly with ROHS certificate
9,Beam Angle: both 120 and 80are available


Technical parameters

Item MS-HBL-150W
Input Voltage AC100V~240V
Freqency Range 50Hz~60Hz
Total Harmonic Distortion less than 9%
Power-factor > 0.9
Power Efficiency > 86%
LED Power 150W
LED chip smd3030
Driver Sosen driver
LED Consumption 100-110LM/W
LED Initial Flux WW (2700K-3300K)
NW (4000-5000K)
CW (5300-7000K)
Center Illuminance Height: 4M 1511.5LUX
Height: 6M 678.3LUX
Height: 8M 416.7LUX
Beam Angle 45/60/90/120°
 Illuminance Area Height: 4M / Ø7.05m
(Light Spot)(Round) Height: 6M / Ø10.37m
Height: 8M / Ø13.69m
Illuminance Uniformity >0.6
Color Rendering Index WW/Ra>68
Light Distribution Symmetry / Light spot (round)
Light Design LED+reflector secondly light distribution
Juction Temperature less than 80°c
Operation Temperature  -40°c to +55°c
Storage Temperature  -25°c to +65°c (26°c is best-fit)
IP Rating IP44
Working Life Span 50,000Hours
Power Line 0.75mm² three-core cable
Connect Wire L/N/G
Housing Material Aluminum



200W led high bay light (2)

Five easy installation methods for led high bay light to adapt to the upgrading and replacement the traditional MH, HID lights.

200W led high bay light (6)

25°60°90°100°110°totally six size of the scale-type reflector which could effectively improve the lighting effiiciency

200W led high bay light (1)



1. Instead of the fluorescent lights indoors
2. School / Universities / Hospital
3. Conference / Meeting room , Show Room
4. commercial establishments
5. Factories / Offices
6. Super-markets
7. Residential / Institution buildings
8. Government lighting engineering, airport, subway

200W led high bay light (5)


Packaging & Delivery

Neutral packing, 1pcs/carton. Design as discussed with clients for led high bay

Embedded packaging, after 2 meters drop test
360-degree all-round protective packaging, 50KG the following impact without damage
