SMD5730 e40 e27 e39 e26 connector led corn light 150w with CE ROHS FCC PSE

SMD5730 e40 e27 e39 e26 connector led corn light 150w with CE ROHS FCC PSE

SMDc5730 LED chips
e40 e27 e39 e26 connector
led corn light 150w
3 years warranty

  • Description

Product Description

SMD5730 e40 e27 e39 e26 connector led corn light 150w with CE ROHS FCC PSE



Features

30w 40w 60w 80w 100w 120w 150w ia available

Input voltage can be selected: AC85-305 or DC12V 24V
1.Those LED Corn Lights are using high brightness of original packed Samsung 5630 SMD chip which acieves 120lm/w
2. As the world’s first new products, LED corn lights could replace the conventional compact CFL light directly .
3 Unique construction design with full beam angle (360°)
4 Fin aluminum heat dissipation system(patent design).
5 No spot, no black area, long life span and less brightness decay
6 Various lamp holder are available , a wide range of applications. (E39/E40, E26/E27)
7 Wide voltage AC85-305V,High efficiency constant current drives, Efficiency of power supply is more than 90%.
8 No magnetic disturbance influence and CE and RoHS standard compliant
9 No UV and near-IR radiation in the light beam.
10 LEDs are protected from bugs,dust,humidity because cover over them
11 There’s no noise since no fans inserted
12 36 months warranty



specifications

The Specification of led corn light
Item No. MS-CNL-30W MS-CNL-40W MS-CNL-60W MS-CNL-80W MS-CNL-100W MS-CNL-120W MS-CNL-150W
Power Consumption 30W 40W 60W 80W 100W 120W 150W
Replace HID Lamp 150-200W 200-300W 300-450W 400-600W 600-1000W 800-1000W 1000-1500W
Dimension/Heat sink 93*195MM 93*195MM 93*205MM 93*229MM 93*241MM 93*265MM 93*338MM
Weight 0.5kg 0.5kg 0.55kg 0.55kg 0.7KG 0.74KG 0.76KG
Lumens 3000-3200LM 3500-4400lm 6000-6600LM 8000-8800LM 10000-11000LM 12500-13200LM 15700-16000LM
Base e40 e27 e39 e26 or hook
Lumous flux 80~100lm/W
Power Factor ≥0.95
LED Power Supply Mean Well driver or High quality driver
AC Input AC85 – 305V  (AC375V available on request)
DC Input DC80~400V  (DC12V, DC24V and other input available on request)
LED Light Source Macro / Bridgelux / Epistar 5730 SMD
Color Temperature 2700~6500K
Beam Angle 360°
Color Rendering Index ≥80
Working Life ≥50000Hrs
Working Temperature -20℃~60℃
Housing Copper Free Aluminum
Warranty 3 Years
Brand of Products MS& Customized
Certificate CE, ROHS
OEM accept



Applications

1. Read the user’s manual in details, make sure the environment conditions fit the requests
2. Cut the power off before installation
3. Do not run e40 led corn light over 300VAC unless it’s labeled.
4. Do not install this bulb in ambient where has high temperature over like 55 celsius degree or over corrosive gas
5. Indoor,Outdoor use in outdoor luminaires (minimum Ip65)
6. Don’t throw away casually

Industrial LED corn light(1) (15)



Packaging & Shipping

Standard export packaging

Industrial LED corn light(1) (18)
